Core Functionality
Modular experimental platform
Multi functional desktop: pre-set M6 threaded hole array (spacing 50mm × 50mm), compatible with expansion accessories such as fixtures, rails, brackets, etc.
Hidden cable tray: Cable trays on both sides of the desktop (width 30mm), supporting centralized management of power cables and sensor data cables.

Integrated Energy System
Dual power supply: independent control of AC/DC output (AC 220V ± 10%, DC 0-24V adjustable), with short-circuit protection function.
Smart socket: designed for child safety doors, with a leakage response time of ≤ 0.1 seconds (compliant with IEC 60884 standard).

Safety And Ergonomic Design
Height adjustable: The table legs are equipped with hand cranked lifting mechanisms (adjustable range 700-800mm), suitable for students of different heights.
Anti collision protection: The table corner is treated with a circular arc (R ≥ 10mm), and the table edge is wrapped with a 2mm thick silicone anti-collision strip.

Flexible Storage Space
Drawer module: Double layered drawer (with a load-bearing capacity of 15kg/layer), adjustable partition board, suitable for classified storage of experimental equipment.
Bottom storage rack: Steel mesh rack (bearing 50kg), used to store backpacks or large equipment (such as power boxes).

Extended Compatibility
Standard interface: Reserved V-shaped groove (compatible with optical guide rail), magnetic attraction area (surface magnetic induction intensity ≥ 200mT).
Optional components: Can be equipped with a sink (PP material), universal clamping arm, and 3D motion guide rail kit.

Safety Certification
Education standards: JY/T 0385-2006 (Experimental Equipment for Primary and Secondary Schools), GB/T 3976-2014 (Hygiene Standards for desks and chairs).
Electrical safety: GB 4706.1 (Safety of Household Appliances), CCC certification (Power Modules).
Environmental certification: ISO 14001 (Environmental Management System), Greenguard (Low Volatile Organic Compounds).
